Description of Home security system:
There are several home security systems out there. Different manufacturers use different techniques and topology in their design. Cameras are also very popular for the purpose of security. Main problem with security cameras is to monitor them. They have capability to record the view in DVR hard drive but they could not stop intruder from intrusion. They are just providing the proof after the incident happens. Whereas in most cases we want to stop an intruder from intrusion. for this purpose different types of alarming systems are developed which warns the intruders not to enter in a specific area. also these system are kind of passive systems which needs only power up and they stays in sort of sleeping mode when everything is normal. They activate an alarm at the time of intrusion. They don't normally need to observe. So such systems are better in the way that all the time monitoring is not needed. Monitoring all the time is not easy. It needs a team of three people minimum all the time to observe the cameras in 24 hours a day. In some very sensitive areas it is mandatory to keep system system in observation all the time but in normal situations an alarming system with no observation is the best choice. Such alarming systems use sort of activating sensing system which is activated by some parameter. mostly they use pyroelectric sensor which are activated by human body temperature. When a person is passing through the pir or piroelectric sensor, its body infrared radiation which is in the form of body temperature activates the pyroelectic sensor and it sends its output signal to an amplifier. The amplifier is amplifying the signal as well there is a timer operation also in the circuit. The amplifier activates a alarm which informs the intruder not to enter in the specific area as you are under observation.

Principle of operation:

1. When power is applied to the circuit, The pir sensor or piroelectric sensor senses human passed in front of it and it produces an electrical signal, the pir sensor output signal from sensor pin 2 is applied to one transistor VT1 and here it is amplified. Without amplification the signal is small enough so that it could not be fed to the next stage, then this signal is applied to the operational amplifier IC2A pin 3 which performed as high gain low noise amplifier stage, and latter the signal is supplied to IC1A for further amplification.
2.  The IC2B works like a voltage comparator and it compares the two inputs. One is the signal coming from the prvious stage and the other is the reference provided by R10 and VD1. Transistor VT is used to drive the output buzzer.
